Budget Stainless Steel Grease Traps with 5 year warranty

How do grease traps work?
Fats, Oils and Grease are lighter than water and as such float on the surface. A Typical conventional trap is a rectangular tank with an internal baffle wall, the baffle divides the system into two chambers. The BSGT also have an internal strainer basket on the inlet to trap solid waste before entering the baffle chamber of the unit.

The BGST grease trap units separates solids first then fat, oil and grease as follows
1) Waste water from the kitchen waste pipes passes into the inlet of the grease trap, this immediately enters the strainer basket and slows the flow down, allowing food waste to be trapped.

2) Once trapped within the baffle wall chamber the fats, oils and grease content floats to the surface.

3) The clean water from the kitchen waste is allowed to pass under the baffle wall and into the main drainage system.
BSGT How It Works cross section

Benefits

  • Single sink or multi-sink applications
  • Capable of handling dishwasher outflow.
  • Easy inlet/ outlet connection with optional rubber couplers
  • Requires minimal space for installation and user maintenance.
  • Easy to retro-fit, uses standard plumbing fittings.
  • Internal or external use (above ground) as made from stainless steel.
  • Quality built with 5 years warranty

Features

  • Incorporates a filter basket on the inlet for effective solids removal along with high percentage fat, oil and grease capture.
  • High quality stainless steel construction
  • Through flow unit, serves any sink/dishwasher volume where recommended installation and cleaning procedures are followed
  • All seams fully welded
  • Connection using standard Multi-fit connectors
  • Quick release watertight lid for simple inspection and cleaning
  • 5 year return to base warranty

Application Guide

Application

Model

Domestic Kitchen / Coffee Machine

Takeaway

Dishwasher

Small Kitchen
10-50 Covers

Medium Kitchen
51-100 Covers

Large Kitchen
101-150 Covers

Extra Large Kitchen
151+ Covers

BSGT1

ü

BSGT3

ü

ü

BSGT8

ü

ü

ü

ü

BSGT12

ü

ü

ü

ü

ü

Sizing Guide

Diagram Measurement (mm)

Model

A

B

C

D

E

F

BSGT1

380

270

230

460

180

50

BSGT3

380

380

310

470

220

50

BSGT8

650

450

340

740

260

50

BSGT12

800

500

390

890

300

50

Cheap Grease Trap
Sort By:
Page of 1
Stainless Steel Domestic Grease Trap with 5-Year Warranty
BSGT1 Domestic Grease Trap
RETAIL PRICE: £229.00 Exc VAT

BSG1 Stainless Steel Grease Trap
Applications:
- Domestic
- Coffee Machine
BSGT3 from Aqua Mundus stainless steel grease trap, 30 litre capacity with food filter basket
BSGT3 Single Sink Grease Trap
RETAIL PRICE: £329.00 Exc VAT

BSGT3 Stainless Steel Grease Trap
Applications:
- Takeaway
- Small Kitchen 10-50 covers
Aqua Mundus BSGT8, 80 litre stainless steel grease trap with food catcher internal basket.
BSGT8 Stainless Steel Grease Trap
RETAIL PRICE: £429.00 Exc VAT

(1)

BSGT8 Stainless Steel Grease Trap
Applications:
- Takeaway
- Dishwasher
- Small Kitchen 10-50 covers
- Medium Kitchen 51-100 covers
Aqua Mundus BSGT12 - 120 litre stainless steel construction grease trap with internal filter basket and optional inlet & outlet rubber couplers
BSGT12 Stainless Steel Grease Trap
RETAIL PRICE: £629.00 Exc VAT

BSGT12 Stainless Steel Grease Trap
Applications:
- Dishwasher
- Small Kitchen 10-50 covers
- Medium Kitchen 51-100 covers
- Large Kitchens 101-150 covers
- Very Large Kitchens 151+ covers
